4″ bore x 30″ stroke cross tube hydraulic cylinder

Description

Bore : 4 in
Outer Dia. () : 4.5 in
Stroke : 30 in
Rod Dia. () : 2 in
Port Size : SAE 8
Pin Dia. () : 1.5 in
Extended : 70 in
Retracted : 40 in
Overall length : 42.25 in
Pressure : 3500 PSI
Column Load : 35,700 LBs
Oil Volume : 6.52 QTs
Design : Welded
Rod Type : Chrome Plated
Rod End : Cross Tube
Action :
Double Acting
Weight : 86 LBs
