3 Bore x 42 Stroke – Welded Crosstube Cylinder

Description

Bore : 3 in
Outer Dia. () : 3.37 in
Stroke : 42 in
Rod Dia. () : 1.5 in
Port Size : SAE 8
Pin Dia. () : 1 in
Extended : 92 in
Retracted : 50 in
Overall length : 51.5 in
Pressure : 3500 PSI
Column Load : 8,400 LBs
Oil Volume : 5.14 Qts
Design : Welded
Rod Type : Chrome Plated
Rod End : Cross Tube
Action :
Double Acting
Weight : 59 LBs
