3″ bore x 10″ stroke cross tube hydraulic cylinder

Description

Bore : 3 in
Outer Dia. (?) : 3.37 in
Stroke : 10 in
Rod Dia. (?) : 1.5 in
Port Size : SAE 8
Pin Dia. (?) : 1 in
Extended : 28 in
Retracted : 18 in
Overall length : 19.5 in
Pressure : 3500 PSI
Column Load : 21,000 LBs
Oil Volume : 1.22 QTs
Design : Welded
Rod Type : Chrome Plated
Rod End : Cross Tube
Action :
Double Acting
Weight : 24 LBs
