3.5″ bore x 16″ stroke cross tube hydraulic cylinder

Description

Bore : 3.5 in
Outer Dia. () : 3.86 in
Stroke : 16 in
Rod Dia. () : 1.75 in
Port Size : SAE 8
Pin Dia. () : 1.25 in
Extended : 42 in
Retracted : 26 in
Overall length : 28 in
Pressure : 3500 PSI
Column Load : 28,800 LBs
Oil Volume : 2.66 QTs
Design : Welded
Rod Type : Chrome Plated
Rod End : Cross Tube
Action :
Double Acting
Weight : 41 LBs
