2″ bore x 8″ stroke cross tube hydraulic cylinder

Description

Bore : 2 in
Outer Dia. (?) : 2.38 in
Stroke : 8 in
Rod Dia. (?) : 1.25 in
Port Size : SAE 6
Pin Dia. (?) : 1 in
Extended : 24 in
Retracted : 16 in
Overall length : 17.5 in
Pressure : 3500 PSI
Column Load : 9,400 LBs
Oil Volume : 0.43 QTs
Design : Welded
Rod Type : Chrome Plated
Rod End : Cross Tube
Action :
Double Acting
Weight : 13 LBs
