2.5″ bore x 20″ stroke cross tube hydraulic cylinder

Description

Bore : 2.5 in
Outer Dia. (?) : 2.875 in
Stroke : 20 in
Rod Dia. (?) : 1.5 in
Port Size : SAE 8
Pin Dia. (?) : 1 in
Extended : 48 in
Retracted : 28 in
Overall length : 29.5 in
Pressure : 3500 PSI
Column Load : 14,700 LBs
Oil Volume : 1.7 QTs
Design : Welded
Rod Type : Chrome Plated
Rod End : Cross Tube
Action :
Double Acting
Weight : 30 LBs
